O-M Ltd.

～Φ1250mm（49.21inch）

VTLex 1250

VTLex 1250

  • Track gaugeΦ1250mm（Φ1450mm）
    Φ49.21inch（Φ57.09inch）
  • Wheel diameterΦ1600mm
    Φ62.99inch
  • Shaft length1250mm（880mm）
    49.21inch（34.65inch）

    ※ Numerals in parentheses"()"above are for APC specifications ( the column, however, is of standard specifications ).
  • Max. weight8000kg（4000kg）
    17600lbs（8800lbs）
    ※ Numerals in parentheses"()"above are for APC specifications ( the column, however, is of standard specifications ).

2-axis control CNC turning.

Combines high rigidity with high speed and high accuracy.

VTLex 1250M

VTLex 1250M

  • Track gaugeΦ1250mm（Φ1450mm）
    Φ49.21inch（Φ57.09inch）

    ※ Numerals in parentheses"()"above are for optional specifications.
  • Wheel diameterΦ1600mm(Φ62.99inch)
  • Shaft length1250mm（880mm）
    49.21inch（34.65inch）

    ※ Numerals in parentheses"()"above are for APC specifications ( the column, however, is of standard specifications ).
  • Max. weight8000kg（4000kg）
    17600lbs（8800lbs）

    ※ Numerals in parentheses"()"above are for APC specifications ( the column, however, is of standard specifications ).

3-axis control CNC turning center

Milling function and table indexing (C axis) function, in addition to turning.

This enables a wide range of machining and centralization of machining processes.

TMMe-12N（Vertical Turning Lathe）

TMMe-12N（Vertical Turning Lathe）

  • Track gaugeΦ1250mm
    Φ49.2inch
  • Wheel diameterΦ1600mm
    Φ63.0inch
  • Shaft length1400mm（1100mm）
    55.1inch（43.3inch）
  • Max. weight8000kg（4000kg）
    17600lbs（8800lbs）

※ Numerals in parentheses"()"above are for APC specifications.

Turning center equipped with three-axis control (X, Y, Z) and table arbitrary-indexing mechanism.

Heavy-duty angle head enables five-face machining with high rigidity.

With the B-axis angle, this single machine can function as a vertical lathe, vertical machining center, horizontal machining center and oblique cutter.

Common bed, single-pole column, 240 mm square ram, and two-face constraint (turning tool) for high rigidity.

TMM-12/16N（Vertical lathe capable of 5-face machining）

TMM-12/16N（Vertical lathe capable of 5-face machining）

  • Track gaugeΦ1250mm
    Φ49.2inch
  • Wheel diameterΦ1600mm
    Φ63.0inch
  • Shaft length1200mm（900mm）
    47.2inch（35.4inch）
  • Max. weight8000kg（4000kg）
    17600lbs（8800lbs）

With its vertical lathe and machining center features, this lathe is capable of various machining steps in a single process and provides great power for combined machining processes for large-sized parts.

The TMM series is a vertical turning center that is ahead of the times.
